WT34-B410 Photoelectric sensors Part no.: 1019229

Photoelectric sensors WT34-B410 Part no.: 1019229




Functional principle

Photoelectric proximity sensor
Functional principle detail Background suppression
Dimensions (W x H x D) 27 mm x 92 mm x 70 mm
Housing design (light emission) Rectangular
Sensing range max. 100 mm ... 2,500 mm 1)
Sensing range 100 mm ... 2,500 mm
Type of light Infrared light
Light source LED 2)
Light spot size (distance) Ø 80 mm (2,500 mm)
Adjustment Potentiometer
1) Object with 90% remission (based on standard white, DIN 5033).

2) Average service life: 100,000 h at TU = +25 °C.
