WL24-2B230 Photoelectric sensors Part no.: 1015852

Photoelectric sensors WL24-2B230  Part no.: 1015852
Functional principle Photoelectric retro-reflective sensor
Functional principle detail With minimum distance to reflector (dual lens system)
Dimensions (W x H x D) 27 mm x 87.5 mm x 65 mm
Housing design (light emission) Rectangular
Sensing range max. 0 m ... 22 m 1)
Sensing range 0 m ... 15 m 1)
Type of light Visible red light
Light source LED 2)
Light spot size (distance) Ø 250 mm (15 m)
Adjustment Potentiometer
1) Reflector PL80A.

2) Average service life: 100,000 h at TU = +25 °C.
