WT24-2B440 Photoelectric sensors Part no.: 1016934

Functional principle Photoelectric proximity sensor Functional principle detail Background suppression Dimensions (W x H x D) 27 mm x 87.5 mm x 65 mm Housing design (light emission) Rectangular Sensing range max. 100 mm ... 1,200 mm 1) Sensing range 100 mm ... 1,200 mm 1) Type of light Visible red light Light source LED 2) Light spot size (distance) Ø 40 mm (1,200 mm) Adjustment Potentiometer 1) Object with 90% remission (based on standard white, DIN 5033). 2) Average service life: 100,000 h at TU = +25 °C.
