DL50-P1123 Part no.: 1047361 Laser distance sensors

DL50-P1123 Part no.: 1047361 Laser distance sensors

Measuring range 200 mm ... 50,000 mm, on “diamond grade” reflective tape 1)
Target Reflector
Resolution 1 mm
Repeatability ≥ 2 mm 2) 3)
Measurement accuracy ± 7 mm
Response time 15 ms ... 30 ms, 15 ms / 30 ms 3) 4)
Output time ≥ 4 ms 5)
Light source Laser, red
visible red light
Type of light Visible red light
Laser class 1 (IEC 60825-1:2014, EN 60825-1:2014) 6)
Typ. light spot size (distance) 15 mm x 15 mm (10 m)
Additional function
Set moving average: fast/slow

Switching mode: distance to object (DtO)

Teach-in, scaling and inversion of digital output

Set hysteresis

Teach-in, scaling and inversion of analog output

Multifunctional input: laser off / external teach / deactivated

Switch-off display
