WTB16P-24161120A00 Part no.: 1218626 Photoelectric sensors

WTB16P-24161120A00 Part no.: 1218626

Photoelectric sensors

Functional principle Photoelectric proximity sensor
Functional principle detail Background suppression
Sensing range
Sensing range min. 10 mm
Sensing range max. 1,000 mm
Adjustable switching threshold for background suppression 100 mm ... 1,000 mm
Reference object Object with 90% remission factor (complies with standard white according to DIN 5033)
Minimum distance between set sensing range and background (black 6% / white 90%) 25 mm, at a distance of 400 mm
Recommended sensing range for the best performance 100 mm ... 400 mm
Emitted beam
Light source PinPoint LED
Type of light Visible red light
Shape of light spot Point-shaped
Light spot size (distance)
