DL35-B15552 Part no.: 1057657 Laser distance sensors

DL35-B15552 Part no.: 1057657 Laser distance sensors

Measuring range 200 mm ... 35,000 mm, on “diamond grade” reflective tape 1)
Target Reflector
Resolution 0.1 mm
Repeatability ≥ 0.5 mm 1) 2)
Measurement accuracy Typ. ± 15 mm 3)
Response time 2.5 ms ... 96.5 ms, 2.5 ms / 6.5 ms / 12.5 ms / 24.5 ms / 96.5 ms 4) 5)
Switching frequency 333 Hz / 100 Hz / 50 Hz / 25 Hz / 6 Hz 4) 5)
Output time 1 ms ... 32 ms, 1 ms/2 ms/4 ms/8 ms/32 ms 4) 6)
Light source Laser, red 7)
visible red light
Type of light Visible red light
Laser class 1 (IEC 60825-1:2014, EN 60825-1:2014)
Typ. light spot size (distance) 15 mm x 15 mm (at 2 m)
Additional function
