IM33-22EX-HI/24VDC Isolating transducer

IM33-22EX-HI/24VDC Isolating transducer

Isolating transducer
2-channel
Order number: 7506441
Power supply of 2-wire measuring transducers with HART communication as well as connection to active 2-wire and passive 3-wire transmitters
Input circuits: 0/4…20 mA
Output circuits: 0/4…20 mA
SIL2
Removable terminal blocks, screwable, with 2 mm test socket
Complete galvanic isolation
Input reverse-polarity protected
ATEX, IECEx, UL, CFMUS, TR CU, CCOE, Kosha
Installation in zone 2
