BL67-2AI-TC BL67 electronic module

BL67-2AI-TC BL67 electronic module

BL67 electronic module
A 2-channel voltage analog input is used for thermocouples
Order number: 6827178
It does not rely on fieldbus and connection technology
Protection grade: IP67
LED indicates status and diagnosis
The electronic circuit is isolated from the field layer through an optocoupler
Two analog inputs are used to connect the thermocouple
Class B, E, J, K, N, R, S, T
Cold junction temperature compensation is achieved through a special connector containing a Pt1000 probe.
